Veterinary High Cost-Effective Electrosurgical Unit WMV630D
Capable of most monopolar and bipolar surgical procedures and packed withdependable safety features, the WMV630D satisfies the veterinarian's demands with precision, safety, and reliability.
PRODUCT DETAILS
Main Feature
| - 3 Monopolar Cut: Pure Cut, Blend 1,Blend 2 - 2 Coag: Spray, Forced - 1 Bipolar Output: Standard - CQM Contact Quality Monitoring System | - Electrosurgical Pens and Foot Switch Control - Recently Mode, Power and Other Parameters - Quick Adjustment of Power and Volume - Cut and Coag in an Intermittent Manner |
Product Specifications
Mode | Max Output Power(W) | Load Impedance(n2) | Modulation Frequency(kHz) | Max Output Voltage (V) | Crest Factor | ||
Monopolar | Cut | Pure Cut | 100 | 500 | -- | 1300 | 1.8 |
Blend 1 | 100 | 500 | 20 | 1400 | 2.0 | ||
Blend 2 | 100 | 500 | 20 | 1300 | 2.0 | ||
Coag | Spray | 90 | 500 | 12-24 | 4800 | 6.3 | |
Forced | 60 | 500 | 25 | 4800 | 6.2 | ||
Bipolar | Standard | 60 | 100 | 20 | 700 | 1.9 | |
Ordering Information
Model | Description | |
WMV630D |
| Electrosurgical Unit |
JBW-200 |
| Monopolar Foot-Switch |
HX-(B1)S |
| Hand-Switch Pencil, Disposable |
38813 |
| Patient Return Electrode Rods(10mm)With Cable, Reusable |
HX-(D)P |
| Bipolar Forceps,Reusable, Connecting Cable |
